SB1 – Shower head
Shower head for the CCT-M fermentation tanks
The shower head (spray ball) is an accessory designed to easy cleaning and sanitizing of surfaces inside the tanks using the CIP station and sanitizing solutions.
It is joining with the upper pipe using a pin to the CP port inside the tank. We offer two types of the shower head – the fixed shower head and the shower with rotational head.
Fixed and rotational shower heads:
Offer for the SB1 shower heads :
- MTS-SB1-DN25F Cleaning spray head 320°⌀65 DN28,5 DN25 for tanks up to 30HL
MTS-SB1-DN25F Static cleaning spray ball 320°⌀65 DN28,5 for DN25 is an optional equipment to cleaning and sanitizing inside of the tank. Intended for tanks with volume up to 30HL. Connection : Split pin on tube DN28,5 (for pipe DN25). Fixed (non-rotating), effective angle 320°. Read more » - MTS-SB1-DN25R Rotational cleaning spray head 180°⌀65 DN25 for tanks up to 30HLMTS-SB1-DN25R Rotational cleaning spray head 180°⌀65 DN28,5 for DN25 connection is an optional equipment to cleaning and sanitizing inside of the tank. Intended for tanks with volume up to 30HL. Connection : Split pin on tube DN28,5 (for pipe DN25). Rotational, effective angle upper 180° . Read more »
WordPress RSS Feed Retriever by Theme Mason
Scheme of the CCT-M modular system with locations of the optional MTA armatures
MTA armatures are optional accessories for equipping of the basic tanks of the CCT-M system. The required configuration of the modular tanks is reached by equipping the basic tank with appropriate combination of MTA armatures.
- MTA armatures – optional accessories for the basic tanks of the CCT-M system
- BT basic tanks – pressure cylindrically-conical fermentors without armatures – main parts of the CCT-M system
- CCT-M modular system – general informations about the modular cylindrically-conical fermentors
