WCS – Wort cooling system
We use these wort cooling systems in a microbrewery BREWORX : System devices, providing cooling wort (produced in the brewhouse) to the desired fermentation temperature. Fermentation temperature depends on the type of beer.
I.a) Split wort cooling system – with separated components
The classical wort cooling system consists of six main parts :
-
Split liquid cooler or Compact liquid cooler
-
Ice cooling water tank
-
Ice treated water tank
-
Hot water tank
-
Wort cooler and aerator
Scheme of the split wort cooling system in breweries Breworx :
I. b) Compact wort cooling system – with all components integrated on common platform
The compact wort cooling system is used as part of the Breworx Modulo brewery modular system. All parts of the wort cooling system are integrated on one platform. The compact wort cooling system consists of :
- Platform – stailess steel frame
- Ice treated water tank – mounted on the frame
- Hot water tank – mounted on the frame
- Wort cooler and aerator – mounted on the frame
- Pumps – mounted on the frame
- Compact cooler – mounted on the frame
We offer two compact systems for cooling the wort – independent WCU unit with wort-cooling equipment and ice water storage tank and independent WCU-HWT unit which consists of WCU and hot water tank.
>> Price list and description of the compact wort cooling units
II. Wort cooler and aerator
We use the compact wort cooler-aerator units for both wort cooling and aeration .
We offer these wort cooling-aeration units :
- WCASB-300 : Compact cooler and aerator of wort 300 liters per hour with LED temperature indicatorsCompact cooler and aeration system for wort 300 liters of wort per hour which is attached to a stainless steel panel with LED temperature indicators. The monoblock system for precisse cooling and aeration of hot wort. This is a necessary equipment for preparation of wort after the hot wort brewing process and before start of the beer fermentation process. Single-stage or double-stage tabular heat exchanger intended for cooling of the wort from 90°C to 25-7°C using water at temperature 15°C and 1°C before starting of beer fermentation process. The plate heat exchanger and the aeration candle are attached to a… Read more »
- WCASB-150 : Compact cooler and aerator of wort 1000 liters per hour with LED temperature indicatorsCompact cooler and aeration system for wort 150 liters of wort per hour which is attached to a stainless steel panel with LED temperature indicators. The monoblock system for precisse cooling and aeration of hot wort. This is a necessary equipment for preparation of wort after the hot wort brewing process and before start of the beer fermentation process. Single-stage or double-stage tabular heat exchanger intended for cooling of the wort from 90°C to 25-7°C using water at temperature 15°C and 1°C before starting of beer fermentation process. The plate heat exchanger and the aeration candle are attached to a… Read more »
- WCASB-5000 : Compact cooler and aerator of wort 5000 liters per hour with LED temperature indicatorsCompact cooler and aeration system for wort 5000 liters of wort per hour which is attached to a stainless steel panel with LED temperature indicators. The monoblock system for precisse cooling and aeration of hot wort. This is a necessary equipment for preparation of wort after the hot wort brewing process and before start of the beer fermentation process. Single-stage or double-stage tabular heat exchanger intended for cooling of the wort from 90°C to 25-7°C using water at temperature 15°C and 1°C before starting of beer fermentation process. The plate heat exchanger and the aeration candle are attached to a… Read more »
- WCASB-800 : Compact cooler and aerator of wort 800 liters per hour with LED temperature indicatorsCompact cooler and aeration system for wort 800 liters of wort per hour which is attached to a stainless steel panel with LED temperature indicators. The monoblock system for precisse cooling and aeration of hot wort. This is a necessary equipment for preparation of wort after the hot wort brewing process and before start of the beer fermentation process. Single-stage or double-stage tabular heat exchanger intended for cooling of the wort from 90°C to 25-7°C using water at temperature 15°C and 1°C before starting of beer fermentation process. The plate heat exchanger and the aeration candle are attached to a… Read more »
- WCASB-6000 : Compact cooler and aerator of wort 6000 liters per hour with LED temperature indicatorsCompact cooler and aeration system for wort 6000 liters of wort per hour which is attached to a stainless steel panel with LED temperature indicators. The monoblock system for precisse cooling and aeration of hot wort. This is a necessary equipment for preparation of wort after the hot wort brewing process and before start of the beer fermentation process. Single-stage or double-stage tabular heat exchanger intended for cooling of the wort from 90°C to 25-7°C using water at temperature 15°C and 1°C before starting of beer fermentation process. The plate heat exchanger and the aeration candle are attached to a… Read more »
- FTTM-B38 : Flow-through thermometer for hose 9.5mm (3/8″)FTTM-B38 is an in-line flow-through thermometer that fits to water and wort temperature indication during the wort cooling process. This thermometer is equipped with two hose connectors (for hoses with inner diameter 3/8inch / 9.5mm). Read more »
- CFTC-95X6 : Counter flow tubular chiller 9.5mm (3/8″) x 5.8m for cooling wort or other liquids (KegLand KL02035)Counter flow tubular chiller - suitable for cooling wort, drinks after pasteurization, etc. Read more »
- SIC-12X8 : Spiral immersion cooler 12.7mm (1/2″) x 8m for cooling wort and other liquids | 35 liters (KegLand KL09614)Spiral immersion cooler for rapid cooling of hot wort before fermentation. Usable for use with a brewhouse with capacity 10-100 liters. Read more »
- SIC-12X11 : Spiral immersion cooler 12.7mm (1/2″) x 11m for cooling wort and other liquids | 65 liters (KegLand KL04787)Spiral immersion cooler D=12.7mm (1/2") x L=11m for rapid cooling of hot wort before fermentation. Usable for use with a brewhouse with capacity 10-100 liters. Read more »
- CFTC-12×6 : Counter flow tubular chiller 12.7mm (1/2″) x 6.5m for cooling wort or other liquids | stainless steel (KegLand KL08747)Counter flow tubular chiller - suitable for cooling wort, drinks after pasteurization, etc. Read more »
