Bottle filling machines – up to 1300 bottles per hour

Machines to filling drinks into bottles

with production capacity up to 1300 bottles per hour

bottle-filling-machines-280x143We offer compact bottle rinsing, filling and capping semi-automatic machines with production capacity up to 1300 bottles per hour for bigger microbreweries and medium breweries. Most operations are performed automatically, a human operator only manually inserts the empty bottle into the machine and then hand stores full bottle in retail packaging.

BFA-CB550-800x800



We offer these machines for filling of beer / cider into bottles :

  • BFSA-MB661 : Monoblock 6-6-1 / Semi-automatic rinsing, filling and capping machine for bottles (up to 600 bph)BFSA-MB661 : Monoblock 6-6-1 / Semi-automatic rinsing, filling and capping machine for bottles (up to 600 bph)
    The monoblock 6-6-1 is a compact bottling machine with three integrated units : Bottle rinsing unit : semi-automatic rinsing the glass bottles (optionally PET bottles) - 6 electronic valves Bottle filling unit : isobaric filling the glass bottles (optionally PET bottles) - 6 electronic valves Bottle capping unit : pneumatic capping the bottles with crown caps (optionally screwed caps, ROPP caps) - 1 capping head with electronic valves, optionally adaptable for aluminium cans, PET bottles, screwed caps, ROPP caps. Production speed : from 400 up to 600 bottles per hour (depending on the operator, product, temperature, foamicity, pressure) Read more »
  • BFSA-MB662 : Monoblock 6-6-2 / Semi-automatic rinsing, filling and capping machine for bottles (up to 600 bph)BFSA-MB662 : Monoblock 6-6-2 / Semi-automatic rinsing, filling and capping machine for bottles (up to 600 bph)
    The monoblock 6-6-2 is a compact bottling machine with three integrated units : Bottle rinsing unit : semi-automatic rinsing the glass bottles (optionally PET bottles) - 6 electronic valves Bottle filling unit : isobaric filling the glass bottles (optionally PET bottles) - 6 electronic valves Bottle capping unit : pneumatic capping the bottles with crown caps (optionally screwed caps, ROPP caps) - 2 capping heads with electronic valves, optionally adaptable for aluminium cans, PET bottles, screwed caps, ROPP caps. Production speed : from 400 up to 600 bottles per hour (depending on the operator, product, temperature, foamicity, pressure) Read more »
  • BFA-MB611 : Automatic counterpressure filling and capping machine for glass bottles and aluminium cans (up to 850 bph)BFA-MB611 : Automatic counterpressure filling and capping machine for glass bottles and aluminium cans (up to 850 bph)
    Compact fully automatic counterpressure filling and capping machine with two integrated units : fully automatic isobaric filling unit for glass bottles and aluminium cans - six electronic valves fully automatic pneumatic capping unit for the bottles with crown caps - one capping head fully automatic unit to capping the aluminium cans - one capping head Operation speed (valid for 330 ml containers) : up to 850 bottles or cans per hour (depending on the operator, product, temperature, foamicity, pressure) Read more »
  • BFSA-MB44 : Monoblock 4-4 / Semi-automatic rinsing and filling machine for bottles (up to 400 bph)BFSA-MB44 : Monoblock 4-4 / Semi-automatic rinsing and filling machine for bottles (up to 400 bph)
    The monoblock 4-4 is a compact machine to rinsing and counter pressure filling the glass bottles with two integrated units : Bottle rinsing unit : semi-automatic rinsing the glass bottles - 4 electronic valves Bottle filling unit : isobaric filling the glass bottles - 4 electronic valves An external bottle capping machine is a recommended accessory. Production speed : from 300 up to 400 glass bottles per hour (depending on the operator, product, temperature, foamicity, pressure) Read more »
  • USAF4-800 : Semi-automatic counter-pressure bottle/cans filling machine (up to 800 pcs per hour)USAF4-800 : Semi-automatic counter-pressure bottle/cans filling machine (up to 800 pcs per hour)
    Universal semi-automatic four-head filling machine for glass bottles and cans with the filling capacity up to 800 containers per hour. The universal counter-pressure filling machine is ideally suited for beverage producers who do not want to be tied to one type of bottle or can. The configuration of the isobarical filling machine can be changed between different bottle sizes in 5 minutes and can be converted from filling the bottles to cans in 20 min. We are an authorized sales partner of the European producer. Read more »
  • USAF6-1200 : Semi-automatic counter-pressure bottle/cans filling machine (up to 1200 pcs per hour)USAF6-1200 : Semi-automatic counter-pressure bottle/cans filling machine (up to 1200 pcs per hour)
    Universal semi-automatic six-head filling machine for glass bottles and cans with the filling capacity up to 1200 containers per hour. The universal counter-pressure filling machine is ideally suited for beverage producers who do not want to be tied to one type of bottle or can. The configuration of the isobarical filling machine can be changed between different bottle sizes in 5 minutes and can be converted from filling the bottles to cans in 20 min. We are an authorized sales partner of the European producer. Read more »
  • ABF8-2200 : Automatic counter-pressure bottle filling machine (up to 2200 bottles per hour)ABF8-2200 : Automatic counter-pressure bottle filling machine (up to 2200 bottles per hour)
    Semi-automatic or fully-automatic eight-head filling machine for one format of glass bottles with the filling capacity up to 1800-2200 bottles per hour.  We offer this machine as a semi-automatic (in the basic version) or a fully-automatic (in the completelly equipped version) bottle filling system with fully automatic bottle rinser, depaletizer and the bottle capping unit (but the crown caps are always inserted manually into the machine). These machines are made for 1 bottle format (usually 0.33L). The format of the bottles is defined by a customer when the machine is ordered. Output capacity is up to 1800 bottles per hour… Read more »
  • ABF36-2200 : Automatic counter-pressure bottle filling and capping machine / up to 2200 bottles per hourABF36-2200 : Automatic counter-pressure bottle filling and capping machine / up to 2200 bottles per hour
    Fully-automatic 6-head counter-pressure filling machine for glass bottles with the filling capacity up to 1800-2200 bottles per hour.  We offer this machine only in a fully-automatic version. Bottles are always automatically loaded into the machine from a conveyor belt, a labeller or a depaletizer. The fully automatic rinser is possible to locate here, which will rinse the bottles before they are filled.   The machine includes an automatic bottle filling system and an autoomatic bottle capping unit (crown caps are feeded automatically).   Read more »
  • GBBFU-6 : Semi-automatic gravity filling machine for bottles, Bag-In-Box and Pouch-Up bags, with the buffer tankGBBFU-6 : Semi-automatic gravity filling machine for bottles, Bag-In-Box and Pouch-Up bags, with the buffer tank
    Semiautomatic filling machine with a buffer tank and an automatic pump designed to gravity filling non-carbonated beverages with low viscosity into glass (or PET) bottles, Bag-In-Box and Pouch-Up bags. The machine has a built-in pump, controlled by level switches in the buffer tank. Filling level in the bottles is adjustable, bottle overfill protection. The filler requires minimal maintenance. Read more »
  • CRCBF-1 : CANNULAR/RAPT Semi-automatic Can and Bottle Filler (Kegland KL37792)CRCBF-1 : CANNULAR/RAPT Semi-automatic Can and Bottle Filler (Kegland KL37792)
    The CANNULAR/RAPT semi-automatic filler from Kegland is the ideal machine for filling beverages into cans and bottles. It is equipped with two adjustable stainless steel nozzles, which allow one nozzle to push the air out of the bottle/can with injected carbon dioxide and the other nozzle to fill the bottle/can exactly to the set level based on the measurements by the integrated pressure sensor. The supply includes an AC 230V / DC 24V source for safe low-voltage power supply of the charger.   Read more »
WordPress RSS Feed Retriever by Theme Mason




Other equipment for filling beverages in bottles and operations associated with bottle filling :








>> I want to receive an offer for this component <<
