AIR COMPRESSOR – production of compressed air
Air Compressor is used in the brewery for the production of compressed air. It is used for various operations and equipment:
- Aeration of the wort before fermentation process (only together with sterilizing air filters)
- Compressed gas to push beer and yeast from containers (only with the use of special procedures – beer must not come into direct contact with the air)
- Pneumatic actuator device (such as a pneumatically-operated lift of raising mixers, pneumatic valves etc.)
- Clean Technology
- Production of nitrogen (together with the nitrogen generator)
We offer these air compressors with air filters and dryers for our brewhouses :
- ACO-82-50OFS : Oil-free super silent air compressor 4.9 m3/h (82 l/min) with pressure tank 50 liters
Piston air compressor of the Super Silent series with a noise level of only 59 dB. Machine output 82 l/min (4.92 m3/h) at 1.1 kW, power supply 1-phase 230V/50Hz. Compact lightweight oil-free piston air compressor with direct drive with a maximum air pressure of 9 bar and an air pressure tank with a volume of 50 liters. The power button is located directly on the unit. Minimal machine maintenance and also very low noise. Read more » - ACO-45-6OFS : Oil-free super silent air compressor 2.7 m3/h (45 l/min) with pressure tank 6 litersPiston air compressor of the Super Silent series with a noise level of only 59 dB. Machine output 45 l/min (2.70 m3/h) at 0.55 kW, power supply 1-phase 230V/50Hz. Compact lightweight oil-free piston air compressor with direct drive with a maximum air pressure of 8 bar and an air pressure tank with a volume of 6 liters. The power button is located directly on the unit. Minimal machine maintenance and also very low noise. Read more »
- ACO-45-10OFS : Oil-free super silent air compressor 2.7 m3/h (45 l/min) with pressure tank 10 litersPiston air compressor of the Super Silent series with a noise level of only 59 dB. Machine output 45 l/min (2.70 m3/h) at 0.55 kW, power supply 1-phase 230V/50Hz. Compact lightweight oil-free piston air compressor with direct drive with a maximum air pressure of 8 bar and an air pressure tank with a volume of 10 liters. The power button is located directly on the unit. Minimal machine maintenance and also very low noise. Read more »
- ACO-184-50OF : Oil-free air compressor 11.0 m3/h (184 l/min) with pressure tank 50 litersPiston air compressor of the oil-free Pro Line Zero series. Machine output 184 l/min (11.0 m3/h) at 1.5 kW, power supply 1-phase 230V/50Hz. Compact lightweight oil-free piston air compressor with direct drive with a maximum air pressure of 10 bar and an air pressure tank with a volume of 50 liters. Automatic run control using Condor's superior pressure switch. Minimal machine maintenance. Read more »
- ACO-230-100OF : Oil-free air compressor 13.8 m3/h (230 l/min) with pressure tank 100 litersPiston air compressor of the oil-free Pro Line Zero series. Machine output 230 l/min (13.8 m3/h) at 2.2 kW, power supply 1-phase 230V/50Hz. Compact lightweight oil-free piston air compressor with direct drive with a maximum air pressure of 10 bar and an air pressure tank with a volume of 100 liters. Automatic run control using Condor's superior pressure switch. Minimal machine maintenance. Read more »
- ACO-230-150OF : Oil-free air compressor 13.8 m3/h (230 l/min) with pressure tank 150 litersPiston air compressor of the oil-free Pro Line Zero series. Machine output 230 l/min (13.8 m3/h) at 2.2 kW, power supply 1-phase 230V/50Hz. Compact lightweight oil-free piston air compressor with direct drive with a maximum air pressure of 10 bar and an air pressure tank with a volume of 150 liters. Automatic run control using Condor's superior pressure switch. Minimal machine maintenance. Read more »
- ACO-230-200OF : Oil-free air compressor 13.8 m3/h (230 l/min) with pressure tank 200 litersPiston air compressor of the oil-free Pro Line Zero series. Machine output 230 l/min (13.8 m3/h) at 2.2 kW, power supply 1-phase 230V/50Hz. Compact lightweight oil-free piston air compressor with direct drive with a maximum air pressure of 10 bar and an air pressure tank with a volume of 200 liters. Automatic run control using Condor's superior pressure switch. Minimal machine maintenance. Read more »
- ACO-350-200OF : Oil-free air compressor 21.0 m3/h (350 l/min) with pressure tank 200 litersPiston air compressor of the oil-free Pro Line Zero series. Machine output 350 l/min (21.0 m3/h) at 3 kW, power supply 3-phase 400V/50Hz. Compact lightweight oil-free piston air compressor with direct drive with a maximum air pressure of 10 bar and an air pressure tank with a volume of 200 liters. Automatic run control using Condor's superior pressure switch. Minimal machine maintenance. Read more »
- ACO-350-270OF : Oil-free air compressor 21.0 m3/h (350 l/min) with pressure tank 270 litersPiston air compressor of the oil-free Pro Line Zero series. Machine output 350 l/min (21.0 m3/h) at 3 kW, power supply 3-phase 400V/50Hz. Compact lightweight oil-free piston air compressor with direct drive with a maximum air pressure of 10 bar and an air pressure tank with a volume of 270 liters. Automatic run control using Condor's superior pressure switch. Minimal machine maintenance. Read more »
- ACO-780-200SO : Oil screw air compressor 46.8 m3/h (780 l/min) with pressure tank 200 liters, with air dryerRevolutionary small screw compressor with an input of 5.5 kW in the concept of traditional piston compressors with a pressure vessel of 200 l. The maximum pressure at the outlet is 10 bar at an air flow of 780 l/min. COOL condensing dryer with dew point +5 °C, electronic condensate discharge and digital PDP-display. Simple maintenance after removing the cover. Suitable for constant intake of compressed air with up to 30% energy savings. Read more »
