MPM | Mobile pump
Equipment to transport of wort, beer, juice, water, sanitizing solutions in the beverage production system
Portable mobile pump in minibrewery uses for:
- The pumping-over beer and its intermediate between vessels
- Cleaning pipes
- Cleaning vessels – usually tanks for production beer
We offer this mobile pump for breweries :
MP-90 Mobile pump 750W
Product Description
Portable mobile pump 750W wor using in brewery/ciderline. The pumping-over beer/cider and santitizing solutions between vessels, cleaning of vessels and pipes.
Technical parameters :
Performance 0,75 kW
Outtake 1 1/4” / DN 40
Intake 1 ” / DN 25
Max. flow range 110 l/min = 6,6 m3/h
Max. working pressure 8,0 Bar
Max. liquid temperature 60 °C
Isolation level F
Safety level IP55
El. connection 3-ph 230/400 V ±10 % 50 Hz
Dimensions w x d x h 435 x 690 x 925 mm
Weight 15 kg
Other pumps for small breweries :
- MP-150SC : Mobile centrifugal pump 1500W with speed control, Stainless steel
Portable stainless steel mobile centrifugal pump 1500W with the speed control for transport beverages between containers, beverage filtraton, cleaning and sanitizing the tanks and pipes. Indended for breweries, cider production plants, wineries and production of all other beverage kinds. Read more » - MP-55 : Mobile centrifugal pump 550W, Stainless steelStainless steel mobile centrifugal pump 550W for transport beverages between containers, beverage filtraton, cleaning and sanitizing the tanks and pipes. Indended for breweries, cider production plants, wineries and production of all other beverage kinds. Read more »
- MP-55SC : Mobile centrifugal pump 550W with speed control, Stainless steelStainless steel mobile centrifugal pump 1500W with the speed control for transport beverages between containers, beverage filtraton, cleaning and sanitizing the tanks and pipes. Indended for breweries, cider production plants, wineries and production of all other beverage kinds. Read more »
- MP-180 : Mobile centrifugal pump 1800W, Stainless steelPortable stainless steel mobile centrifugal pump 1800W for transport beverages between containers, beverage filtraton, cleaning and sanitizing the tanks and pipes. Indended for breweries, cider production plants, wineries and production of all other beverage kinds. Read more »
- MP-180SC : Mobile centrifugal pump 1800W with speed control, Stainless steelStainless steel mobile centrifugal pump 1800W with the speed control for transport beverages between containers, beverage filtraton, cleaning and sanitizing the tanks and pipes. Indended for breweries, cider production plants, wineries and production of all other beverage kinds. Read more »
- FJP-3000MG : Fruit juice pump – 3000 liters per hourThe FJP-3000MG fruit juice pump is equipment for the transport of fruit juice (pressed fruit mash) from under the fruit press to the fermentation tanks. Capacity is 3000 kg of fruit juice per hour. Read more »
- MGP-MKII25 : Magnetic pump 25W with a stainless steel head – suitable for drinks and liquids (temperature up to 120°C)Small magnetic pump with stainless steel core , motor power 25W, designed for use in the smallest breweries or beverage producion systems. The pumping-over beverages between tanks, during beer filtering process or cooling of the wort. Suitable also for pumping the santitizing solutions between vessels, cleaning the vessels and pipes. The power cord with the plug connector 1ph 220-240 Volts at 50-60hz (the european standard). Read more »
- MGP-MKII65 : Magnetic pump 65W with a stainless steel head – suitable for drinks and liquids (temperature up to 120°C)Small magnetic pump with stainless steel core , motor power 65W, designed for use in smaller breweries or beverage producion systems. The pumping-over beverages between tanks, during beer filtering process or cooling of the wort. Suitable also for pumping the santitizing solutions between vessels, cleaning the vessels and pipes. The power cord with the plug connector 1ph 220-240 Volts at 50-60hz (the european standard). Read more »
- MGP-U12P18 : Magnetic pump 12V with a power of 18W suitable for clean drinks and liquids (temperature max. 35°C)Small magnetic pump with power 18W and power supply voltage 12V, designed for use in the smallest breweries or beverage producion systems. The pumping-over beverages between tanks, during beer filtering process or cooled wort. Read more »
- PDP-GFA1222 : Pneumatic stainless steel diaphragm pump Graco Saniforce 1040 FA1222 4.8-9.3 m3/hr (FDA certificate for use with food)The Graco Saniforce 1040 FA1222 pneumatic stainless steel diaphragm pump with theFDA certification for feeding beer or other beverages. This device works without electrical consumption – it needs only pressure air and a pressure reduction valve. Minimalized mechanical impact on beer. Pump volume power : 102 - 204 liters / min. (4.8 - 9.3 m3 / hour) This pump includes a certificates for use with food processing - CE, ATEX, IECEx, 1935/2004/EC and FDA (125 Ra) Read more »
