3-rd solution – BREWORX MOBILE CIP

The CIP station is very necessary equipment in every brewery. Its function is perfect cleaning, sanitizing and disinfecting of all vessels and piping routes. Without regular care of the cleanliness of all equipment brewery is not possible to produce quality drinks.

We offer very operative solution for the cleaning and sanitizing of your brewery :

The Breworx mobile CIP station

Its function is based on circulation of an alkaline or acid solution through a sanitary shower spraying it onto vessel walls and into its space.

It is equipped also with a flowheater with digital regulation of temperatures ranging from 0°C to 80°C.

The CIP station consists of two main tank for alkaline and acid solution and one vessel for neutralizing of used solutions.

The circulation of the sanitizing solutions is provided by an integrated centrifugal pump and system of connecting hoses.

Main advantage of our CIP station is its mobility. You can easy to move it between tanks around the brewery.

The equipment CIP 50 is installed in a rigid a frame provided with lockable travel wheels.

Material is stainless steel 1.4301 (AISI 304).

Very easy cleaning and sanitation process

A construction of the CIP station allows the cleaning and sanitation of all pipe routes and vessels in ten steps :

Filling of hot water into the cleaned tank
Hot cleaning cycle – a circulation of hot water from the tank through a heating chamber (reheating of water) and back to the tank using the pump. Water is poured into sewers or storaged in the waste hot water tank after the end of this cycle.
Pre-heating of alkaline solution in the tank no.5
Alkaline sanitation cycle – the hot alkaline solution circulates several minutes through the tank, pump, heating chamber and sprayball. It is storaged in the tank no.5 after the of this cycle.
Pre-heating of acid solution in the tank no.4
Acid sanitation cycle – the hot acid solution circulates several minutes through the tank, pump, heating chamber and sprayball. It is storaged in the tank no.4 after the of this cycle.
Filling of cold drinking water into the cleaned tank
Cold cleaning cycle – a circulation of cold drinking water from the tank through a heating chamber (heating of water) and back to the tank using the pump. Water is poured into sewers after the end of this cycle.
Sterilization cycle – all the tank and pipes you can sterilize using hot steam from the steam generator (it is not included in the CIP station – we offer the steam generator as separate device).
Neutralization cycle – if the acid and alkaline solution are already very dirty then you can pour both solutions to neutralization vessel – when the resulting solution is chemically neutral, then is poured into sewers.

We offer these types of CIP stations for small breweries :

CIP-1503 : Cleaning and sanitizing station 3×1500 liters (the static CIP machine)
The CIP-1503 is a machine to the sanitation and sterilization of vessels and piping routes. This is a fully equipped system for breweries and other food production plants : Cleaning-In-Place. The CIP equipment provides heating and circulation of water, alkaline and acid solutions through sanitary shower that sprays sanitary chemical solutions on the wall of a vessel. The device consists of three separate containers with nominal volume of 1500 liters and one neutralization vessel (270 l), one or two centrifugal pumps, manual and automatic valves and all installation pipes as well. The steam version of the CIP station includes also… Read more »
CIP-A1503 : Automatic control system for CIP-1503
CIP-A1503 is an automatic control system for the Cleaning In Place system CIP-1503. The automatization includes all functions necessary to perfect cleaning and sanitation of all containers and optionally also pipes and hoses in a brewery using a special program, sensors, pneumatic valves and industrial computer with the touch display. This control system is compatible with the CIP-1503 machine. Read more »
CIP-A2003 : Automatic control system for CIP-2003
CIP-A2003 is an automatic control system for the Cleaning In Place system CIP-2003. The automatization includes all functions necessary to perfect cleaning and sanitation of all containers and optionally also pipes and hoses in a brewery using a special program, sensors, pneumatic valves and industrial computer with the touch display. This control system is compatible with the CIP-2003 machine. Read more »
CIP-2003 : Cleaning and sanitizing station 3×2000 liters (the static CIP machine)
The CIP-2003 is a machine to the sanitation and sterilization of vessels and piping routes. This is a fully equipped system for breweries and other food production plants : Cleaning-In-Place. The CIP equipment provides heating and circulation of water, alkaline and acid solutions through sanitary shower that sprays sanitary chemical solutions on the wall of a vessel. The device consists of three separate containers with nominal volume of 2000 liters and one neutralization vessel (360 l), one or two centrifugal pumps, manual and automatic valves and all installation pipes as well. The steam version of the CIP station includes also… Read more »
CIP-32 : Cleaning and sanitizing station 2×30 liters (the mobile CIP machine)
CIP station 2x30 liters is a mobile machine to the sanitation and sterilization of vessels and piping routes. This is a fully equipped system for breweries and other food production plants : Cleaning-In-Place. The CIP equipment provides heating and circulation of alkaline and acid solutions using a pump through pipe system, hoses and sanitary shower that sprays sanitary chemical solutions on interior walls of the sanitized vessel. This type of the CIP station is recommended for cleaning and sanitation of fermentation tanks, storage tanks, water tanks with volume from 0 up to 1200 liters and all piping routes and other… Read more »
CIP-AM2 : Automatic control system for CIP-102/202
CIP-AM2 is an automatic control system for the mobile Cleaning In Place systems with two tanks. The automatization includes all functions necessary to perfect cleaning and sanitation of all containers and optionally also pipes and hoses in a brewery using a special program, sensors, motorized valves and PLC industrial computer with the no-touch display. This control system is compatible only with the CIP-102 and CIP-202 machines. Read more »
CIP-AM3 : Automatic control system for CIP-103/203
CIP-AM3 is an automatic control system for the mobile Cleaning In Place systems with three tanks. The automatization includes all functions necessary to perfect cleaning and sanitation of all containers and optionally also pipes and hoses in a brewery using a special program, sensors, motorized valves and PLC industrial computer with the no-touch display. This control system is compatible only with the CIP-103 and CIP-203 machines. Read more »
CIP-A302 : Automatic control system for CIP-302
CIP-A302 is an automatic control system for the mobile Cleaning In Place system CIP-302. The automatization includes all functions necessary to perfect cleaning and sanitation of all containers and optionally also pipes and hoses in a brewery using a special program, sensors, motorized valves and PLC industrial computer with the no-touch display. This control system is compatible only with the CIP-302 machine. Read more »
CIP-A3003 : Automatic control system for CIP-2003
CIP-A3003 is an automatic control system for the Cleaning In Place system CIP-3003. The automatization includes all functions necessary to perfect cleaning and sanitation of all containers and optionally also pipes and hoses in a brewery using a special program, sensors, pneumatic valves and industrial computer with the touch display. This control system is compatible with the CIP-3003 machine. Read more »
CIP-3003 : Cleaning and sanitizing station 3×3000 liters (the static CIP machine)
The CIP-3003 is a machine to the sanitation and sterilization of vessels and piping routes. This is a fully equipped system for breweries and other food production plants : Cleaning-In-Place. The CIP equipment provides heating and circulation of water, alkaline and acid solutions through sanitary shower that sprays sanitary chemical solutions on the wall of a vessel. The device consists of three separate containers with nominal volume of 3000 liters and one neutralization vessel (360 l), one or two centrifugal pumps, manual and automatic valves and all installation pipes as well. The steam version of the CIP station includes also… Read more »
